Tungsten weight cylinders balance squares for hot sale
+
  • Tungsten weight cylinders balance squares for hot sale

Tungsten weight cylinders balance squares for hot sale

MOQ:7-15KGS

Delivery Time:3-4 days

Keywords:

Insert for coal mining

Product Description

Application



1.Tungsten heavy alloy can be widely used as balancing weights and high temperature moulds;

2.They can also be used as protection shields for high-energy rays;

3.Electro-heat upsetting anvil block and the core of armour piercing shell also adopt tungsten heavy alloy as material;

4.They are also offered as machinable blanks or precision machined parts according to customers’ requirements;

5.Tungsten heavy alloys also can be used for producing aircraft control surfaces, helicopter rotor systems, engine components, ship ballasts, golf club weights, boring bars and down hole sinker bars, etc;

6.They can be produced as the materials for making fire arms and ordnance.



Tungsten alloy cylinder/Tungsten weight weight specifications:



1. Diameter: 2.0-100.0mm
2. Length: 50-1000mm
3. Density: 16.5-18.75g/cm3
4. Composition: Tungsten content: 85-99%, W-Ni-Fe, W-Ni-Cu
5. Surface: sintered, polished surface, polished surface



Grade Density Hardness Tensile Strength Rate of elongation Impact toughness
g/cm] HRC NPa %  J/m²
W273 17.10±0.15 >23 >900 >24  1.30
W263 17.25±0.15 >23 >900 243  1.20
W253 17.40±0.15 ≥24 >900 >22  1.10
W243 17.60±0.15 ≥24 >920 >20  0.9.
W232 18.10±0.15 >25 >920 >14  0.45
W231 18.30±0.15 >26 ≥920 >12  0.30
Y221 18.50±0.15 >27 ≥920 10  0.22
WNiCu 16.00-18.50 >22 450 2-8    ————
